[vc_row][vc_column][vc_column_text css=”.vc_custom_1477422504470{margin-bottom: 0px !important;border-bottom-width: 0px !important;padding-bottom: 0px !important;}”]Home > Original Series Gooseneck Highboy Trailers >[/vc_column_text][heading heading=”h2″]GHB148 Gooseneck Highboy Trailer[/heading][heading heading=”h5″]14,000 GVW[/heading][/vc_column][/vc_row][vc_row][vc_column width=”2/3″][vc_row_inner css=”.vc_custom_1437069597001{margin-top: 0px !important;margin-bottom: 0px !important;border-top-width: 0px !important;border-bottom-width: 0px !important;padding-top: 0px !important;padding-bottom: 0px !important;}”][vc_column_inner][vc_button title=”FIND A DEALER” target=”_blank” color=”btn-inverse” size=”btn-small” href=”https://doubleatrailers.ca/dealerlocator/” el_class=”find-a-dealer-button”][vc_button title=”PDF BROCHURE” target=”_blank” color=”btn-inverse” size=”btn-small” href=”https://doubleatrailers.ca/wp-content/uploads/2022/11/GHB148-Gooseneck.pdf” el_class=”pdf-brochure-button”][/vc_column_inner][/vc_row_inner][vc_gallery interval=”5″ images=”8168,8169,8170,8171″ img_size=”full” onclick=””][tabs][tab title=”STANDARD FEATURES”]
| Axle Size | (2) 7,000 lb; Electric Brakes |
| Width | 102" Overall Width |
| Lace Rail | 5" Channel with Pockets & Rubrail |
| Coupler | GN 2 5/16" Adjustable Ball or Kingpin |
| Crossmembers | 3" Channel on 18" Centers |
| Tire & Rim | 235/80R16 |
| Landing Gear | (2) 12,000 lb |
| Toolbox | None |
| Safety Chains | 5/16 Grade 70 Chain with Grab Hooks |
| Wiring | Arctic Wiring, Soldered & Enclosed in Conduit |
| Lights | Rubber Mounted LED (30' & up come with side signal) |
| Decking | 2" Treated Wood, fastened with 1/4" Torx Screws |
| Steps | Steps & Grab Handles on each side |
| Finish | Sandblasted and Painted with PPG Urethane Paint |
[/tab][tab title=”MODEL SPECS”]
| 20' | Main Frame: 10@15lb Carrying Capacity: 9,996 lbs Tare Weight: 4,004 lbs |
| 22' | Main Frame: 10@15lb Carrying Capacity: 9,703 lbs Tare Weight: 4,297 lbs |
| 24' | Main Frame: 10@15lb Carrying Capacity: 9,410 lbs Tare Weight: 4,590 lbs |
| 26' | Main Frame: 10@15lb Carrying Capacity: 9,117 lbs Tare Weight: 4,883 lbs |
| 28' | Main Frame: 10@15lb Carrying Capacity: 8,824 lbs Tare Weight: 5,176 lbs |
| 30' | Main Frame: 12@16lb Carrying Capacity: 8,531 lbs Tare Weight: 5,469 lbs |
| 32' | Main Frame: 12@16lb Carrying Capacity: 8,238 lbs Tare Weight: 5,762 lbs |
[/tab][/tabs][/vc_column][vc_column width=”1/3″ css=”.vc_custom_1435618223998{background-color: #c6c6c6 !important;}”][vc_column_text el_class=”quote-builder-button”]
[/vc_column_text][vc_row_inner el_class=”contact-sales-widget-row”][vc_column_inner][vc_widget_sidebar sidebar_id=”contact-sales—trailer” el_class=”contact-sales-widget”][/vc_column_inner][/vc_row_inner][vc_gallery type=”image_grid” images=”2316,2305,4178″ onclick=”link_no” el_class=”gallery-tags”][vc_separator el_class=”separator”][vc_column_text css=”.vc_custom_1437103651050{margin-bottom: 2px !important;border-bottom-width: 0px !important;padding-bottom: 0px !important;}”]
Popular Options
[/vc_column_text][vc_column_text]
[/vc_column_text][vc_column_text css=”.vc_custom_1431400243476{margin-bottom: 2px !important;border-bottom-width: 0px !important;padding-bottom: 0px !important;}”]
All GVW’s For This Trailer
[/vc_column_text][vc_wp_custommenu nav_menu=”112″ el_class=”gvw-menu”][vc_empty_space height=”2px”][/vc_column][/vc_row]
